The Hyundai HYCP5030 compactor/wacker plate is powered by an 87cc four-stroke recoil start petrol engine, with a large 1.6 litre fuel tank for long running.
This machine is ideal for compacting loose soil, gravel and sand together to create a solid and even foundation, providing a cost-effective alternative to hiring for the building, construction and landscaping industries.
Fitted with a large plate measuring 495mm long x 320mm wide, combined with a travelling speed of 25 metres per minute, the Hyundai HYCP5030 will make quick work of large areas, with a compaction depth of 150mm.
Designed for building patios, driveways, block paving, garage extensions and conservatory foundations, the HYCP5030 compactor plate comes with a paving pad to protect patios and block paving from any marks or damage during use.
The V-belt is covered by a guard which protects it from the knocks and bumps of construction work. The wheel kit assists with transporting the compactor from one job to the next. The throttle control is conveniently mounted on the handle, which also has a soft grip cover for increased comfort. To make storage easy, the handles can be folded down over the main unit.
Brand | Hyundai |
---|---|
Engine | Hyundai |
Engine Type | 4-stroke, single cylinder, OHV |
Displacement | 87cc |
Start Method | Recoil |
Fuel | Unleaded petrol |
Fuel Tank Capacity | 1.6L |
Centrifugal Force | 8200N |
Plate Size | L: 59.5 x W: 32cm |
Compaction Depth | 150mm |
Travelling Speed | 25m/min |
Exciter Speed | 5900rpm |
Oil Capacity | 0.15L |
Vibration Level Data | ≤ 17.5m/s² |
Sound and Noise Data | 86dB(A) |
Assembled Dimensions | L: 115cm x W: 66cm x H: 85cm |
Weight | 46.5kg |
Warranty | 3 years |
